Servo Motor (3.2 kg.cm - Standard)

Overview

This standard servo motor delivers 3.2 kg.cm of torque at 6V, making it a perfect balance of power, size, and cost for your robotics and automation projects. Whether you're building a robotic arm, a pan-tilt camera mount, or an RC vehicle, this motor offers precise angle control and reliable performance.

Key Features

• High Torque: 3.2 kg.cm at 6V, sufficient for many small to medium robotic applications.
• Fast Response: 0.16 sec/60° at 6V for quick and accurate movements.
• Lightweight: At only 36g, it won't weigh down your project.
• Wide Voltage Range: Operates from 4.2V to 6V, compatible with common power sources.
• Standard Size: 40.8 x 20.1 x 38 mm, fits standard servo mounts and horns.
• Precise Positioning: Ideal for applications requiring angular control.

Technical Specifications

• Speed: 0.18 sec/60° (4.8V), 0.16 sec/60° (6V)
• Torque: 3 kg.cm (4.8V), 3.2 kg.cm (6V)
• Weight: 36g
• Voltage: 4.2-6V
• Dimension: 40.8 x 20.1 x 38 mm

Applications & Use Cases

• Robotic arms and grippers
• Pan-tilt camera mounts
• RC cars, boats, and airplanes
• Animatronics
• Automated window openers
• Educational robotics kits

What's Included

• 1x Servo Motor (3.2 kg.cm - Standard)
• 1x Standard servo horn set (cross, round, and spline)
• 1x Mounting screws

Compatibility

• Works with all standard servo controllers, receivers, and Arduino, Raspberry Pi, and other microcontroller boards.
• Compatible with standard 3-pin connectors (VCC, GND, Signal).

MOKWN Recommendation

This servo is an excellent choice for hobbyists and students who need reliable performance without breaking the bank. For higher torque requirements, consider our MG996R (9.4 kg.cm) or DS3218 (20 kg.cm) options. For smaller projects, our SG90 (1.8 kg.cm) is a great alternative. All our servos are tested for quality and backed by MOKWN's commitment to customer satisfaction.
