Servo Motor (10 kg.cm - Double Axis Metal Gear)

Overview

Upgrade your robotics and RC projects with the MOKWN Servo Motor (10 kg.cm - Double Axis Metal Gear). This high-torque digital servo delivers exceptional performance and durability, making it ideal for demanding applications. The dual-axis design provides flexible mounting options and easy integration with aluminum servo arm kits. Whether you're building a robotic arm, a hexapod, or a remote-controlled vehicle, this servo offers the power and precision you need.

Key Features

• High Torque: Up to 10 kg.cm of stall torque at 6V, providing robust force for heavy-duty tasks.
• Durable Metal Gears: Metal gear train ensures long-lasting performance and resistance to wear and tear.
• Dual-Axis Design: Two output shafts allow for flexible mounting and easy integration with various servo accessories.
• Digital Control: Precise positioning and smooth operation with digital signal processing.
• Wide Voltage Range: Works with 4.8V to 7.4V, compatible with most microcontrollers and RC receivers.
• Lightweight: At only 59 grams, it adds minimal weight to your project.

Technical Specifications

• Weight: 59 gm
• Gear Type: Metal
• Stall Torque: 9 kg.cm (4.8V) / 10 kg.cm (6V)
• Required Pulse: 500~2500 µs
• Operating Angle: 180°
• Operating Speed: 0.18 sec/60° (4.8V) / 0.16 sec/60° (6V)
• Operating Voltage: 4.8V~7.4V
• Connector Wire Length: 30 cm

Applications & Use Cases

• Robotics: Ideal for robotic arms, grippers, and walking robots.
• RC Vehicles: Perfect for steering and throttle control in RC cars, boats, and planes.
• Automation: Suitable for small-scale automation projects requiring precise movement.
• Education: Great for STEM projects and university-level engineering courses.
• 3D Printing: Can be used in DIY 3D printer upgrades for filament or bed leveling.

What's Included

• 1x Servo Motor (10 kg.cm - Double Axis Metal Gear)
• 1x Standard servo horn set (may vary)
• 1x Mounting hardware (screws)

Compatibility

• Compatible with Arduino, Raspberry Pi, and other microcontrollers (via PWM signal).
• Works with standard RC receivers and servo controllers.
• Pairs well with MOKWN's aluminum servo arm kits for enhanced mounting options.

MOKWN Recommendation

For Egyptian makers and engineers, this servo motor offers an excellent balance of torque, durability, and price. Whether you're a student working on a graduation project or a hobbyist building a custom robot, the MOKWN Servo Motor (10 kg.cm - Double Axis Metal Gear) is a reliable choice. Order today and take your project to the next level!
