Connector XT60 ( male )

Overview

The Connector XT60 (male) is a high-current, gold-plated connector designed for reliable power connections in RC models, drones, battery packs, and various electronic projects. Its robust construction and low resistance ensure efficient power transfer, making it a staple for hobbyists and professionals alike. This male connector pairs perfectly with female XT60 connectors to create a secure, vibration-resistant connection that can handle up to 60A continuously.

Key Features

• High Current Capacity: Rated for continuous currents up to 60A, with a peak of 120A (per manufacturer specs), ideal for demanding applications.
• Gold-Plated Contacts: Ensure low resistance and excellent conductivity, minimizing power loss and heat generation.
• Durable Construction: Made from high-temperature-resistant nylon housing, capable of withstanding harsh conditions.
• Secure Connection: The bullet-style connectors provide a firm, reliable fit that resists accidental disconnection.
• Easy Soldering: Designed for straightforward soldering with ample space for wire connections (up to 12 AWG).
• Polarity Protection: Unique shape prevents reverse polarity connection, safeguarding your equipment.

Technical Specifications

• Connector Type: XT60 Male
• Current Rating: 60A continuous (120A peak)
• Voltage Rating: Up to 60V DC
• Contact Material: Gold-plated copper alloy
• Housing Material: High-temperature nylon (PA66)
• Wire Gauge Compatibility: 12 AWG to 18 AWG
• Operating Temperature: -20°C to +120°C
• Contact Resistance: ≤0.5mΩ
• Mating Cycles: 1000+ cycles

Applications & Use Cases

• RC Models: Connects LiPo batteries to ESCs in cars, boats, and aircraft.
• Drones and UAVs: Essential for power distribution boards and battery connections.
• Battery Packs: Ideal for building or repairing custom battery packs.
• Power Supplies: Used in bench power supplies and chargers.
• DIY Electronics: Perfect for high-current projects like e-bikes, robots, and inverters.

What's Included

• 1x XT60 Male Connector (sold individually)

Compatibility

• Pairs with any standard XT60 female connector.
• Compatible with XT60 to XT60, XT60 to T-plug, and XT60 to banana adapters.
• Works with most LiPo batteries, ESCs, and chargers that use XT60 connectors.

MOKWN Recommendation

For Egyptian makers and engineers, the XT60 male connector is a reliable choice for high-current applications. We recommend using it with quality silicone wire and proper soldering techniques to ensure maximum performance. Whether you're building a drone, upgrading your RC car, or designing a power distribution system, the XT60 connector delivers the durability and efficiency you need.
