TMA2415S - Traco Power DC/DC Converter

Overview

Introducing the TMA2415S from Traco Power, a miniature, isolated 1W DC/DC converter engineered for space-constrained applications. This through-hole module provides reliable, regulated power conversion in a compact SIP-6 package, making it the perfect solution for board-level power distribution in embedded systems, industrial controls, and IoT devices.

Key Features

• Miniature SIP-6 Package: Occupies minimal PCB space (19.56 mm x 7.11 mm x 10.16 mm), ideal for compact designs.
• Isolated 1W Output: Provides safe galvanic isolation for sensitive circuits.
• Input Voltage: 24 V nominal, with wide input voltage range for flexibility.
• Single Output: Delivers a stable output voltage (24 V) with a current rating of 65 mA.
• Through-Hole Mounting: Easy to integrate into standard PCB layouts.
• Wide Operating Temperature Range: -40°C to +85°C, suitable for demanding environments.

Technical Specifications

• Manufacturer: TRACO Power
• Series: TMA
• Product Type: Isolated DC-DC Converter
• Input Voltage (Nominal): 24 V
• Output Voltage: 24 V
• Output Current: 65 mA
• Output Power: 1 W
• Number of Outputs: 1
• Isolation: Yes
• Mounting Style: Through Hole
• Package/Case: SIP-6
• Dimensions: 19.56 mm (L) x 7.11 mm (W) x 10.16 mm (H)
• Operating Temperature: -40°C to +85°C
• Subcategory: DC-DC Converters

Applications & Use Cases

• Industrial Control Systems: Isolated power for sensors, microcontrollers, and communication interfaces.
• IoT Devices: Compact power conversion for smart sensors and wireless modules.
• Embedded Electronics: Board-level power distribution in space-limited designs.
• Telecommunications: Reliable isolated power for line cards and network equipment.
• Test & Measurement: Clean, isolated power for precision instruments.

What's Included

• 1 x TMA2415S DC/DC Converter Module

Compatibility

• Works with standard 24V power rails.
• Compatible with most microcontrollers, sensors, and logic circuits requiring a 24V isolated supply.
• Through-hole SIP-6 package fits standard breadboards and PCBs.

MOKWN Recommendation

For Egyptian engineers and makers seeking a compact, reliable isolated power solution, the TMA2415S is an excellent choice. Its small footprint and robust performance make it ideal for prototyping and production. Pair it with our range of input capacitors and PCB sockets for a complete power solution. Order now and elevate your project with trusted Traco Power quality.
