SMA Male RF Connector (Straight)

Overview

The SMA Male RF Connector (Straight) is a high-quality, 50-ohm RF connector designed for PCB mounting. It features a straight body with a male pin, making it an ideal choice for connecting antennas to GPS modules, cellular modems, and other RF devices in your projects. Whether you're prototyping a new IoT device or integrating wireless connectivity into an existing design, this connector delivers reliable performance and easy integration.

Key Features

• Straight SMA Male Connector: Designed for PCB mounting, providing a secure and stable connection.
• 50 Ohm Impedance: Ensures optimal signal integrity for RF applications.
• Male Pin: Compatible with standard SMA female connectors and cables.
• Durable Construction: Built to withstand repeated mating cycles and environmental stress.
• Easy Soldering: Designed for straightforward PCB soldering, perfect for prototyping and production.

Technical Specifications

• Connector Type: SMA Male
• Orientation: Straight
• Impedance: 50 ohms
• Mounting Style: PCB Mount
• Contact Type: Male Pin
• Body Material: Brass with gold or nickel plating (typical)
• Insulator Material: PTFE (typical)

Applications & Use Cases

• GPS Modules: Connect external antennas for improved satellite reception.
• Cellular Modules: Interface with GSM, 3G, 4G, and 5G antennas.
• Wi-Fi and Bluetooth: Extend range with external antennas.
• RFID Systems: Connect readers to antennas.
• IoT Prototypes: Quickly integrate RF connectivity into your designs.
• Test and Measurement: Use with RF test equipment and adapters.

What's Included

• 1x SMA Male RF Connector (Straight, PCB Mount)

Compatibility

• Works with any SMA female connector or cable.
• Compatible with GPS modules, cellular modems, and RF development boards that require an external antenna.
• Standard 50-ohm RF systems.

MOKWN Recommendation

For Egyptian makers and engineers building wireless projects, this SMA Male connector is a must-have. Its 50-ohm impedance and straight PCB mount design make it perfect for clean, low-loss antenna connections. Stock up on a few to keep your prototypes and products running smoothly. Pair it with our range of SMA cables and antennas for a complete RF solution.
